Hello everyone, Today we will create an Onboarding - Walkthrough application, which is an interface explaining application information, privacy policy or usage policy.

You can download all the image used in the explanation from here

First, we add colors

<?xml version="1.0" encoding="utf-8"?>
<resources>
    <color name="purple_200">#FFBB86FC</color>
    <color name="purple_500">#F61313</color>
    <color name="purple_700">#400A0A</color>
    <color name="teal_200">#FF9800</color>
    <color name="teal_700">#E91E63</color>
    <color name="black">#FF000000</color>
    <color name="white">#FFFFFFFF</color>
    <color name="tab_indicator_gray">#E38C8E</color>
    <color name="intro_title_color">#EB5B5F</color>
    <color name="intro_description_color">#656565</color>
</resources>

Then we increase the theme


<resources xmlns:tools="http://schemas.android.com/tools">
    <!-- Base application theme. -->
    <style name="Theme.MyApplication" parent="Theme.MaterialComponents.DayNight.DarkActionBar">
        <!-- Primary brand color. -->
        <item name="colorPrimary">@color/purple_500</item>
        <item name="colorPrimaryVariant">@color/purple_700</item>
        <item name="colorOnPrimary">@color/white</item>
        <!-- Secondary brand color. -->
        <item name="colorOnSecondary">@color/black</item>
        <!-- Status bar color. -->
        <item name="android:statusBarColor" tools:targetApi="l">?attr/colorPrimaryVariant</item>
        <!-- Customize your theme here. -->
    </style>
</resources>

Then we create a new folder in res in which to place the animation file

<?xml version="1.0" encoding="utf-8"?>
<set xmlns:android="http://schemas.android.com/apk/res/android">

    <alpha
        android:fromAlpha="0.0"
        android:toAlpha="1.0"
        android:duration="500" />

    <translate
        android:fromYDelta="-100%"
        android:toYDelta="0%"
        android:duration="700" />
</set>

Then we create a new file in the layout folder we call "layout_screen.xml"

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="#ffffff">

    <androidx.constraintlayout.widget.Guideline
        android:id="@+id/guideline"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:orientation="horizontal"
        app:layout_constraintGuide_percent="0.56882256" />

    <TextView
        android:id="@+id/intro_title"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginStart="16dp"
        android:layout_marginLeft="16dp"
        android:layout_marginEnd="16dp"
        android:layout_marginRight="16dp"
        android:layout_marginBottom="8dp"
        android:text="TextView"
        android:textColor="@color/intro_title_color"
        android:textSize="32dp"
        android:textStyle="bold"
        app:layout_constraintBottom_toTopOf="@+id/guideline"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="@+id/guideline" />

    <TextView
        android:lineSpacingExtra="16dp"
        android:id="@+id/intro_description"
        android:layout_width="0dp"
        android:layout_height="wrap_content"
        android:layout_marginStart="32dp"
        android:layout_marginLeft="32dp"
        android:layout_marginTop="8dp"
        android:layout_marginEnd="32dp"
        android:layout_marginRight="32dp"
        android:layout_marginBottom="8dp"
        android:text="TextView"
        android:textColor="#676767"
        android:textAlignment="center"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toBottomOf="@+id/intro_title"
        app:layout_constraintVertical_bias="0.13" />

    <ImageView
        android:id="@+id/intro_img"
        android:layout_width="wrap_content"
        android:layout_height="222dp"
        android:layout_marginStart="8dp"
        android:layout_marginLeft="8dp"
        android:layout_marginEnd="8dp"
        android:layout_marginRight="8dp"
        android:layout_marginBottom="32dp"
        app:layout_constraintBottom_toTopOf="@+id/intro_title"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        tools:srcCompat="@tools:sample/backgrounds/scenic" />
</androidx.constraintlayout.widget.ConstraintLayout>

We are changing the layout responsible for the activity in this xml file

<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:tools="http://schemas.android.com/tools"
    xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="#fff"
    xmlns:app="http://schemas.android.com/apk/res-auto">

    <androidx.viewpager.widget.ViewPager
        android:id="@+id/screen_viewpager"
        android:layout_width="0dp"
        android:layout_height="0dp"
        android:layout_marginBottom="8dp"
        app:layout_constraintBottom_toTopOf="@+id/tab_indicator"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent"
        app:layout_constraintTop_toTopOf="parent" />

    <Button
        android:id="@+id/btn_next"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginEnd="32dp"
        android:layout_marginRight="32dp"
        android:textColor="#EB5B5F"
        android:layout_marginBottom="16dp"
        android:drawableRight="@drawable/ic_arrow_forward_black_24dp"
        android:text="Next"
        app:layout_constraintBottom_toBottomOf="parent"
        android:background="@drawable/menuback"
        app:layout_constraintEnd_toEndOf="parent" />

    <com.google.android.material.tabs.TabLayout
        android:id="@+id/tab_indicator"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginStart="32dp"
        android:layout_marginLeft="32dp"
        android:layout_marginEnd="8dp"
        android:layout_marginRight="8dp"
        android:layout_marginBottom="16dp"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toStartOf="@+id/btn_next"
        app:layout_constraintHorizontal_bias="0.0"
        app:layout_constraintStart_toStartOf="parent"
        app:tabBackground="@drawable/indicator_selector">

    </com.google.android.material.tabs.TabLayout>

    <Button
        android:visibility="invisible"
        android:id="@+id/btn_get_started"
        android:layout_width="132dp"
        android:layout_height="wrap_content"
        android:layout_marginStart="8dp"
        android:layout_marginLeft="8dp"
        android:layout_marginEnd="8dp"
        android:layout_marginRight="8dp"
        android:layout_marginBottom="64dp"
        android:background="@drawable/menuback"
        android:text="Get Started"
        android:textColor="#EB5B5F"
        app:layout_constraintBottom_toBottomOf="parent"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintStart_toStartOf="parent" />

    <TextView
        android:textSize="16sp"
        android:textStyle="bold"
        android:textColor="#EB5B5F"
        android:id="@+id/tv_skip"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_marginTop="24dp"
        android:layout_marginEnd="24dp"
        android:layout_marginRight="24dp"
        android:text="Skip"
        app:layout_constraintEnd_toEndOf="parent"
        app:layout_constraintTop_toTopOf="parent" />
</androidx.constraintlayout.widget.ConstraintLayout>

Now we come to the programming stage. We are creating a new class that we call "ScreenItem.java"

package com.cometoplay.myapplication;

public class ScreenItem {

    String Title,Description;
    int ScreenImg;

    public ScreenItem(String title, String description, int screenImg) {
        Title = title;
        Description = description;
        ScreenImg = screenImg;
    }

    public void setTitle(String title) {
        Title = title;
    }

    public void setDescription(String description) {
        Description = description;
    }

    public void setScreenImg(int screenImg) {
        ScreenImg = screenImg;
    }

    public String getTitle() {
        return Title;
    }

    public String getDescription() {
        return Description;
    }

    public int getScreenImg() {
        return ScreenImg;
    }
}

As in the previous stage, we are creating a new class that we call "IntroViewPagerAdapter.java"

package com.cometoplay.myapplication;

import android.content.Context;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ImageView;
import android.widget.TextView;

import androidx.annotation.NonNull;
import androidx.viewpager.widget.PagerAdapter;

import java.util.List;

public class IntroViewPagerAdapter extends PagerAdapter {

    Context mContext ;
    List<ScreenItem> mListScreen;

    public IntroViewPagerAdapter(Context mContext, List<ScreenItem> mListScreen) {
        this.mContext = mContext;
        this.mListScreen = mListScreen;
    }


    @NonNull
    @Override
    public Object instantiateItem(@NonNull ViewGroup container, int position) {

        LayoutInflater inflater = (LayoutInflater) mContext.getSystemService(Context.LAYOUT_INFLATER_SERVICE);
        View layoutScreen = inflater.inflate(R.layout.layout_screen,null);

        ImageView imgSlide = layoutScreen.findViewById(R.id.intro_img);
        TextView title = layoutScreen.findViewById(R.id.intro_title);
        TextView description = layoutScreen.findViewById(R.id.intro_description);

        title.setText(mListScreen.get(position).getTitle());
        description.setText(mListScreen.get(position).getDescription());
        imgSlide.setImageResource(mListScreen.get(position).getScreenImg());

        container.addView(layoutScreen);

        return layoutScreen;
    }

    @Override
    public int getCount() {
        return mListScreen.size();
    }

    @Override
    public boolean isViewFromObject(@NonNull View view, @NonNull Object o) {
        return view == o;
    }

    @Override
    public void destroyItem(@NonNull ViewGroup container, int position, @NonNull Object object) {

        container.removeView((View)object);

    }
}

We are now filling out orders of juveniles

package com.cometoplay.myapplication;

import androidx.appcompat.app.AppCompatActivity;
import androidx.viewpager.widget.ViewPager;

import android.content.Intent;
import android.content.SharedPreferences;
import android.os.Bundle;
import android.view.View;
import android.view.Window;
import android.view.WindowManager;
import android.view.animation.Animation;
import android.view.animation.AnimationUtils;
import android.widget.Button;
import android.widget.TextView;

import com.google.android.material.tabs.TabLayout;

import java.util.ArrayList;
import java.util.List;

public class intro extends AppCompatActivity {

    private ViewPager screenPager;
    IntroViewPagerAdapter introViewPagerAdapter ;
    TabLayout tabIndicator;
    Button btnNext;
    int position = 0 ;
    Button btnGetStarted;
    Animation btnAnim ;
    TextView tvSkip;
    Boolean visible = false;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        requestWindowFeature(Window.FEATURE_NO_TITLE);
        getWindow().setFlags(WindowManager.LayoutParams.FLAG_FULLSCREEN,
                WindowManager.LayoutParams.FLAG_FULLSCREEN);


        // when this activity is about to be launch we need to check if its openened before or not

        if (restorePrefData()) {

            Intent mainActivity = new Intent(getApplicationContext(),MainActivity.class );
            startActivity(mainActivity);
            finish();


        }

        setContentView(R.layout.activity_intro);

        // hide the action bar

        getSupportActionBar().hide();

        // ini views
        btnNext = findViewById(R.id.btn_next);
        btnGetStarted = findViewById(R.id.btn_get_started);
        tabIndicator = findViewById(R.id.tab_indicator);
        btnAnim = AnimationUtils.loadAnimation(getApplicationContext(),R.anim.button_animation);
        tvSkip = findViewById(R.id.tv_skip);

        // fill list screen

        final List<ScreenItem> mList = new ArrayList<>();
        mList.add(new ScreenItem("Title Tablayout","Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua, consectetur  consectetur adipiscing elit",R.drawable.img1));
        mList.add(new ScreenItem("Title Tablayout","Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua, consectetur  consectetur adipiscing elit",R.drawable.img2));
        mList.add(new ScreenItem("Title Tablayout","Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua, consectetur  consectetur adipiscing elit",R.drawable.img3));

        // setup viewpager
        screenPager =findViewById(R.id.screen_viewpager);
        introViewPagerAdapter = new IntroViewPagerAdapter(this,mList);
        screenPager.setAdapter(introViewPagerAdapter);

        // setup tablayout with viewpager

        tabIndicator.setupWithViewPager(screenPager);

        // next button click Listner

        btnNext.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {

                position = screenPager.getCurrentItem();
                if (position < mList.size()) {

                    position++;
                    screenPager.setCurrentItem(position);


                }

                if (position == mList.size()-1) { // when we rech to the last screen

                    // TODO : show the GETSTARTED Button and hide the indicator and the next button

                    loaddLastScreen();


                }



            }
        });

        // tablayout add change listener


        tabIndicator.addOnTabSelectedListener(new TabLayout.BaseOnTabSelectedListener() {
            @Override
            public void onTabSelected(TabLayout.Tab tab) {

                if (tab.getPosition() == mList.size()-1) {
                    loaddLastScreen();
                }
                else if(visible == true)
                {
                    btnNext.setVisibility(View.VISIBLE);
                    btnGetStarted.setVisibility(View.INVISIBLE);
                    tvSkip.setVisibility(View.VISIBLE);
                    tabIndicator.setVisibility(View.VISIBLE);
                    visible = false;
                }



            }

            @Override
            public void onTabUnselected(TabLayout.Tab tab) {

            }

            @Override
            public void onTabReselected(TabLayout.Tab tab) {

            }
        });



        // Get Started button click listener

        btnGetStarted.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {


                //open main activity

                Intent mainActivity = new Intent(getApplicationContext(),MainActivity.class);
                startActivity(mainActivity);
                savePrefsData();
                finish();



            }
        });

        // skip button click listener

        tvSkip.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View v) {
                screenPager.setCurrentItem(mList.size());
            }
        });



    }

    private boolean restorePrefData() {


        SharedPreferences pref = getApplicationContext().getSharedPreferences("myPrefs",MODE_PRIVATE);
        Boolean isIntroActivityOpnendBefore = pref.getBoolean("isIntroOpnend",false);
        return  isIntroActivityOpnendBefore;



    }

    private void savePrefsData() {

        SharedPreferences pref = getApplicationContext().getSharedPreferences("myPrefs",MODE_PRIVATE);
        SharedPreferences.Editor editor = pref.edit();
        editor.putBoolean("isIntroOpnend",true);
        editor.commit();


    }

    // show the GETSTARTED Button and hide the indicator and the next button
    private void loaddLastScreen() {

        btnNext.setVisibility(View.INVISIBLE);
        btnGetStarted.setVisibility(View.VISIBLE);
        tvSkip.setVisibility(View.INVISIBLE);
        tabIndicator.setVisibility(View.INVISIBLE);
        // TODO : ADD an animation the getstarted button
        // setup animation
        btnGetStarted.setAnimation(btnAnim);
        visible = true;



    }
}
